Gewiss GW62474 90°, 16A, 2P+E Angled Surface Mounting Socket 4H Outlet 100-130V
Product Details
- Colour: Yellow
- Rated current (A): 16
- IP degree: IP44
- No. of poles: 2P+E
- Mechanical resistance: IK09
- Reference: 4H
- Type: 90° angled surface-mounting socket-outlet
- Rated voltage: 100 - 130 V
- Frequency: 50/60 Hz
- Terminal tightening capacity: 1-2.5mm² flexible cables - 1.5-4mm² rigid cables
- Operating temperature: -25 +55 °C
- Type of wiring: With screw
- Type of material: Halogen-free in compliance with EN 60754-2
- Electrocod: 2210
- Glow wire test: 850 °C (active parts) - 850 °C (passive parts)
- Total number of operations: > 5000
- Permissible overload: 22 A
- Breaking capacity at 1.1 Un: 20 A
- Insulation resistance: > 10 MΩ
$11.44
Gewiss GW62474 90°, 16A, 2P+E Angled Surface Mounting Socket 4H Outlet 100-130V—
$11.44
Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Product Details
- Colour: Yellow
- Rated current (A): 16
- IP degree: IP44
- No. of poles: 2P+E
- Mechanical resistance: IK09
- Reference: 4H
- Type: 90° angled surface-mounting socket-outlet
- Rated voltage: 100 - 130 V
- Frequency: 50/60 Hz
- Terminal tightening capacity: 1-2.5mm² flexible cables - 1.5-4mm² rigid cables
- Operating temperature: -25 +55 °C
- Type of wiring: With screw
- Type of material: Halogen-free in compliance with EN 60754-2
- Electrocod: 2210
- Glow wire test: 850 °C (active parts) - 850 °C (passive parts)
- Total number of operations: > 5000
- Permissible overload: 22 A
- Breaking capacity at 1.1 Un: 20 A
- Insulation resistance: > 10 MΩ
