Hager NBN363A 63A, 3-Pole, 10kA-15kA, B-Type MCB
Technical Details
- Number of Modules: 3
- Curve: B
- Rated operational voltage Ue: 400 V
- Rated current: 63 A
- Type of supply voltage: AC
- Dimensions (HxWxD): 83 x 52.5 x 70mm
- Rated Frequency: 50/60 Hz
- Rated insulation voltage: 500 V
- Rated impulse withstand voltage: 6000 V
- Rated service breaking capacity Ics AC according IEC 60898-1: 7.5 kA
- Rated service breaking capacity Ics under 400V AC according IEC 60947-2: 7.5 kA
- Rated short circuit breaking capacity Icn under 230V AC according IEC60898-1: 10 kA
- Total power loss under IN: 19.9 W
-
Standard text:
- EN 60898-1
- IEC 60947-2
- European directive WEEE: concerned
- Electric endurance in number of cycles: 4000
- Number of mechanical operations: 20000
- Protection index IP: IP20
$16.13
