Knights D20 Grade 1 5 Screw Single Reed Surface Contact

Product Description

A basic 5 screw flush contact. Two nickel screws to govern the reed switch and 3 spare screws for any custom requirements.

Comes complete with fitting screws.



Product Details



• Environmental Class: II – Indoor uncontrolled



• Terminals: 5 screw



• Tamper: None



• Colour: White



• Operating Gap: ~20mm



• Plate Dimensions: 67mm x 14mm x 12mm



• Materials: White ABS plastic



• Magnet: Ferrite



• Contact Material: Rhodium



• Activation: Reed switch




• Voltage Range: 1 – 100v DC, 125v AC Max



• Switching Current: 500mA Max DC, 500mA Max AC
